DIN 17100

Standard: ASTM A36, ASTM A283, ASTM A572, ASTM A656, JIS G3101 SS400, EN10025-2, DIN 17100, DIN 17102, GB/T700, GB/T1591
Surface Treatment: Oiled, black painted, shot blasted, hot dipped galvanized
Certifications: ISO 9001,SGS,BV
Delivery Time: 7-10 Days
Payment Term: T/T, L/C, WeChat pay, Alipay, etc
Transport: Suit for all kinds of transport, or as required

The company has sufficient inventory and can be picked up at any time.

sales@lhsteelgroup.com

Product Description

Carbon Steel Coil

Standard:

ASTM A36, ASTM A283, ASTM A572, ASTM A656, JIS G3101 SS400, EN10025-2, DIN 17100, DIN 17102, GB/T700, GB/T1591

Surface Treatment: Oiled, black painted, shot blasted, hot dipped galvanized

Certifications: ISO 9001,SGS,BV

Delivery Time: 7-10 Days

Payment Term: T/T, L/C, WeChat pay, Alipay, etc

Transport: Suit for all kinds of transport, or as required


PRODUCT DESCRIPTION

Cold Rolled/ Hot Rolled Carbon Steel Coil
Product NameCold Rolled/ Hot Rolled Carbon Steel Coils Price
StandardDIN GB ISO JIS BS ASTM AISI etc
MaterialQ195 Q215 Q235 Q345 SS490 SM400 SM490 SPHC SPHD SPHE SPHFSEA1002SEA1006 SEA1008 SEA1010 S25C S35C S45C 65Mn SPHT1 SPHT2 Material SPH3 SPH4QstE and etc
Thickness(mm)0.3mm-80mm Thin plate: <4 mm Medium plate: 4-20mm Thick plate: 20-60 mm Ultra thick plalte: >60mm
Length1-12m
Width500,610,760,840,900,914,1000,1200,1250,1500 mm
Technical method  cold rolled, hot rolled
Surface treatmentPrimary. Oiled, Galvanized, Anti-corrosion
PackageTied up with steel strips and wrapped with water proof paper thick platesare packed separately, thin plate are packed in bundles
ApplicationWidely used in ship, automobile, Bridges, buildings, machinery.pressure vessels and other manufacturing industries.



Carbon steel is the most widely used of all steels. It is very strong, durable and corrosion-resistant. Pilotage provides various carbon steel specifications and sizes for your specific application, in the form of strip, coil and plate. Carbon steel cold-rolled strip/coil/plate is a tough and elastic material, which can be used for many purposes. This is an excellent choice for blades, tools and equipment. We are proud to provide the highest quality carbon steel on the market at a reasonable price.

Specification Parameters

Product Specification and Steel Grade (For Reference)

ApplicationJISASTMSAE
Commercial QualityG3141 SPCCA1008 CS Type A, B, C1008~1012 CQ
Drawing QualityG3141 SPCDA1008 DS Type A, B1006~1008 DQ
Deep Drawing QualityG3141 SPCE (N)A1008 DDS1006 DDQ


Available Size

Carbon Steel Hot Rolled Coil / Strip

Thickness (mm)Mill EdgeWidth (mm)Cut EdgeWidth (mm)Coil InsideDiameter (mm)
Coil1.50~6.50720~1860
762
Coil6.51~10.00850~1500
762
Strip1.50~6.50
30~720762
Carbon Steel Hot Rolled Plate / Sheet

Thickness (mm)Mill EdgeWidth (mm)Length (mm)
Plate6.00~150500~40001200~18000
Sheet1.50~5.9950~1845760~6100


HOT ROLLED STEEL COIL

Hot-rolled coils are made of semi-finished products, reduced to a certain thickness by rolling and annealing, and wound into coils. Hot rolled steel is used to manufacture pipes, steel doors and storage tanks, or further processed into cold rolled steel.


COLD ROLLED STEEL COIL

By "pickling" the hot-rolled sheet in a weak acid solution, then cleaning, brushing, drying, oiling and spreading the sheet, and finally cold-rolling the sheet by passing it through a reducing mill under pressure and winding it into a coil, rust is removed from the hot-rolled sheet, thus producing a cold-rolled sheet in the form of a coil. Cold-rolled steel is a product with higher processing degree, with smoother surface, higher dimensional accuracy (thickness, width and length) and higher strength. Many cold-rolled steels are used in the automobile industry, but some are also used to make household goods.

Difference between stainless steel and carbon steel

The difference between stainless steel and carbon steel is that they contain chromium and in some cases nickel. Chromium is added to carbon steel to make it more rust-proof and pollution-resistant. When nickel is added to chromium stainless steel, it enhances mechanical properties, such as density, heat capacity and strength. For example, stainless steel plates are used to make machines, tools and containers.


If you are unsure of which particular type of steel product is the best fit for your requirement or if you would like to learn and know more about steel in general, as well as what we currently have in stock (and what we have the ability to procure for you), feel free to contact one of our knowledgeable sales associates to assist you in the process.

Product Display


Video

Company Profile

Shandong Linghang Steel Group Co., Ltd. is located in Jinan, Shandong Province, with convenient transportation. The company was established in 2020 with a registered capital of 20 million yuan.
Currently, there are nearly 100 employees. This company specializes in producing stainless steel.Steel plate, stainless steel tube, stainless steel bar and other stainless steel profiles. In addition, it also produces various alloy plates. The main materials of our products are TP304/304L, TP316/316L, TP321, 310S, 904L, S31803, 2520Si2, Monel400, etc. There is in the company the annual output of various stainless steel products is more than 10,000 tons, mainly including Used in petroleum, chemical industry, shipbuilding, construction, decoration, semiconductor, Automobile engine, locomotive braking system, gas equipment manufacturing, instruments and meters Equipment, food processing, catering, brewing and other industries.
